3D MACHINE CONTROL FOR EXCAVATORS

Description

MOBA XSITE Pro 3D Machine Control Excavator

The Xsite® PRO ADVANCED has extensive 3D functionalities. 3D terrain models can be imported via common file formats and used without time-consuming conversion. Using the representation on the high resolution display, the excavator driver can perform complex projects with ease. With two GNSS sensors, both the position and the alignment of the machine, are known at all times so that precise working is possible.

The possibility to save points allows to document the working process. The work log is sent to the office via an Internet connection or USB stick. Remote support is available in the event of questions. This system is advantageous if complex projects are performed such as during freeway construction.

Features:

  • Highly compatible Open file formats XML, DXF… can be loaded directly
  • 8.4” rugged touch-screen display with large working screen with easy to navigate tabs
  • 5 times more processing power then any 3D system on the market today
  • Robust, water-tight Tri Axis Sensors
  • All cables and Tri Sensors are the same
  • CAN bus Technology via uniformed connection
  • Common user-friendly gestures are used on the display
  • Full Multi Constellation GNSS
  • Trimble OEM GNSS board allowing for common protocols, message types and frequencies.
  • Free Remote support, no annual service charge
  • Life time free firmware updates
  • 36 months Standard warranty



XSITE® PRO ADVANCED SYSTEM COMPONENTS

Xsite® PRO Operating Panel

  • Easy to operate
  • 4 inch rugged touch-screen colour display
  • Clear visible overview for the operator
  • Transflective TFT-LCD
  • Touch screen type: capacitive
  • CAN-Interface









LED Display XD-2

  • Displays current working status
  • Clearly visible LEDs















Gravitation sensor

  • Measuring range: 360°
  • Ingress Protection IP67
  • Water tight
  • CAN-Interface
  • Robust, compact design





Controller

  • Processes all incoming position data
  • Compares the position of the bucket with the design data



GNSS antenna (single/dual)

  • Easy handling for installation and servicing
  • Receives the position and elevation data of the machine





Omni C18 Industrial Base Station

  • Multi constellation L1/L2 GNSS module
  • Trimble BD990 OEM GNSS board inside
  • Embedded NTrip Caster and Web Server on GNSS Board
  • RTK Accuracy: 8mm Horizontal – 15mm Vertical (Rover Mode)
  • Aluminium Alloy Housing
